Afore AF4K-SLP - Multi Inverter Parallel

Installation
18
Note:
The meter only communicates with the host and does not
communicate with the machine. Refer to chapters 4.3.5.
4.3.3 Mul� Inverter Parallel
3
1-2
4-5
6
7-8
PIN
Assignment
485-A2
/
RJ45 Plug
12345 678
/
/
485-B2
3
1-2
4-5
6
7-8
PIN
Assignment
485-A2
/
RJ45 Plug
12345 678
/
/
485-B2
3
1-2
4-5
6
7-8
PIN
Assignment
485-A2
/
RJ45 Plug
12345 678
/
/
485-B2
485A 485B
Grid
Meter
Load
Cri�cal LoadSmart Load
Cri�cal LoadSmart Load
Cri�cal LoadSmart Load
