Afore BNT030KTL - Page 10

Installation
08
No.
1
2
3
4
5
6
DC Switch
DC Connectors ( + ) For PV Strings
DC Connectors ( − ) For PV Strings
AC Connector
Monitor Module Port
Zero-lnjection Port (Optional)
Items
BNT060KTL
D
3
6
1
1
2
4
5
