1.About This Manual
1.1 Scope of Validity
1.2 Target Group
1.3 System Diagram
This manual describes the installation, commissioning, operation and
maintenance of the following on-grid PV inverters produced by Afore New
Energy:
This manual is for qualified personnel. The tasks described in this manual must
only be performed by qualified personnel.
Three-Phase
BNT030KTL BNT036KTL BNT040KTL BNT050KTL BNT060KTL
Please keep this manual available all the time in case of any emergency.
About This Manual
01
The typical on-grid PV system connection diagram.
BNT030KTL BNT036KTL BNT040KTL
DCA-
DCA-
DCA+
DCA+
DCB-
DCB-
DCB+
DCB+
DCC -
DCC-
DCC+
DCC+
PV Inverter
WIFI / RS485
Cloud server
Web APP
PE
Circuit Breaker
N
L1
AC Grid
Surge Protective
Device
L2
L3
Circuit Breaker Surge Protective
Device
PVA
PV Array
Circuit Breaker
Surge Protective
Device
Circuit Breaker
Surge Protective
Device
PVC
PVB
PV Array
PV Array
