Electrical Connection
17
The monitoring module could transmit the data to the cloud server, and display
the data on the PC, tablet and smart-phone.
WIFI / Ethernet / GPRS / RS485 communication is applicable to the inverter.
Please refer to "Communication Configuration Instruction" for detailed
instruction.
Install the WIFI / Ethernet / GPRS / RS485 Communication
4.4 Communication Connection
Step 1
Step 2
Turn on the DC switch and AC circuit breaker, and wait until the LED indicator
on the monitoring module flashes, indicating that the monitoring module is
successfully connected.
Fasten
