Electrical Connection
16
Step 3
Step 2
Fix the AC wiring cover with cover screws
Unscrew the row of screws, insert the wire harness into the
N, L1, L2, L3 caps one by one, and tighten the screws.
N = Neutral line
L1, L2, L3 = Live line
PE = Earth cable
Note:
The user must connect a protective earth (PE) terminal to prevent
electric shock. And make sure this PE terminal is properly grounded.
