Electrical Connection
14
Note:
PV string suggestion:
Do not connect more than two PV strings into one channel
Channel A, B, C and D connected with PV strings separately
Correct Installation:
Wrong Installation:
D
D
PV +
PV -
PV +
PV -
PV +
PV -
PV +
PV -
PV +
PV -
PV +
PV -
PV +
PV -
PV +
PV -
PV Array 1
PV Array 3
PV Array 2
PV Array 4
PV Array 1
PV Array 3
PV Array 2
PV Array 4
PV Inverter
PV Inverter
