Type of Fault
Code Name Description Recommend Solution
E49
E50
BusUnbalancedFault
BusSwUnderVoltFault
Bus voltage under as
running
DC Bus voltage
unbalanced
F01
F02
InvHwOverCurrFault
HwOverFault
Hardware detected that
current over / BUS voltage
over
F03
F04
InvSOverCurrFault
InvROverCurrFault
R phase /Split phase L1
current over
Hardware detected that
inverter current over
S phase /Split phase L2
current over
F05
InvTOverCurrFault
T phase current over
F06 GridUnbalanCurrFault
3 phase current effective
value has big difference
F07
DcInjOverCurrFault
DC injection current over
The phase-locked loop is
operating abnormally, and
it does not stably track
the grid voltage phase.
It is detected that the
relay group 1 cannot be
opened or closed
normally.
F08 AcOverLeakCurrFault
Ac side leakage current
over
E45
E46
BusHwOverHalfVoltFault
BusHwOverVoltFault
E47
E48
BusSwOverHalfVoltFault
BusSwOverVoltFault
Bus voltage over
• Power off, then restart.
• If fault still occurs continuously and
frequently, please ask help for local
distributors.
• Power off, then restart.
• If fault still occurs continuously and
frequently, please ask help for local
distributors.
• Check if PV panels has good ground
insulation and ground wires are
connected well ground is well, then
repair it.
• Power off, then restart.
• If fault still occurs continuously and
frequently, please ask help for local
distributors.
E33
E34
DC Fault
AC Fault
Boost2SelfCheckFault
Boost1SelfCheckFault
PV boost circuit abnormal
when self checking
• Power off, then restart.
• If fault still occurs continuously and
frequently, please ask help for local
distributors.
F09
F10 GridRelay1Fault
PLLFault
• Power off, then restart.
• If fault still occurs continuously and
frequently, please ask help for local
distributors.
