Afore HNS TL-1 Series User Manual

26
Nominal AC Voltage (V)
220 / 230
Nominal AC Frequency (Hz)
50 / 60
Power Factor
-0.95
～
+0.95
Output current THD
<3%
Feed in Starting Power(W)
42
40
30
30
30
30
Power consumption
Power consumption at Night
(W)
<0.2
<0.2
<1
<1
<1
<1
Power consumption at
Standby (W)
6
6
6
6
6
6
Power Efficiency
Max.Efficiency
96.50%
96.50%
97.70%
97.70%
97.70%
97.70%
Euro Efficiency
96.00%
96.00%
96.60%
96.90%
97.00%
97.00%
MPPT Efficiency
＞99.9%
＞99.9%
＞99.9%
＞99.9%
＞99.9%
＞99.9%
Safety and protection
Safety Standard
EN/IEC 62109-1/-2
EMC Standard
EN/IEC 61000-6, EN/IEC 61000-3
Anti-islanding Protection
Intenal
General information
Dimensions (H×W×D) [mm]
320*345*170
360*345*170
Enclosure
IP65
Pollution degree
3
UV protection
Aluminium
RCD
Internal
Weight [kg]
9
12
Ambient Temperature Range
-25℃ ~ +60℃
Humidity range
0% ~ 100%
Topology
Transformerless
Communication Interface
RS485/WI-FI/Wire Ethernet/GPRS (optional)
Cooling Concept
Convection
Noise Emission [dB]
＜28
Elevation
Up to 2000m without derating
Anyhome Series(Double MPPT Trackers)
Electrical Specifications
HNS3000TL
HNS3600TL
HNS4000TL
HNS5000TL
HNS6000TL
HNS7000TL
HNS8000TL
Input (DC)
Max DC Power (W)
3300
3960
4400
5500
6600
7700
8800
Max DC Voltage (V)
550
550
550
550
550
550
550
Rated/Recommended
Voltage (V)
360
360
360
360
380
380
380
MPPT DC Voltage Range (V)
120-450
120-450
120-450
120-450
120-450
120-450
120-450
Start up DC Voltage (V)
150
150
150
150
150
150
150
Turn off DC Voltage (V)
120
120
120
120
120
120
120
Max DC Current (A)
12*2
15*2
16*2
18*2
18*2
18*2
18*2
Isc PV (A)
15*2
18.5*2
20*2
22.5*2
22.5*2
22.5*2
22.5*2
