Afore HNS TL-1 Series User Manual

27
Number of MPPT Tracker
2
2
2
2
2
2
2
Number of DC connections
(set)
2
2
2
2
2
2+1
2+1
Max Backfeed Current (mA)
＜
1
＜
1
＜
1
＜
1
＜
1
＜
1
＜
1
Output (AC)
Power Connector
Single Phase Three Wire
Max AC Power (W)
3100
3700
4100
5100
6100
7100
8000
Nominal AC Power (W)
3000
3600
4000
5000
6000
7000
8000
Max.AC Current (A)
15
16
20
23
28
31
33
Nominal AC Current (A)
13
16
18
22
26
30
32
Max AC Inrush Current (A)
13
16
18
22
26
30
32
Max AC Fault Current (A)
19.5
24
27
33
39
45
48
Max AC Protect Current (A)
19.5
24
27
33
39
45
48
Nominal AC Voltage (V)
220 / 230
Nominal AC Frequency (Hz)
50 / 60
Power Factor
-0.95
～
+0.95
Output current THD
<3%
Feed in Starting Power(W)
30
30
30
30
30
30
30
Power consumption
Power consumption at Night
(W)
<1
<1
<1
<1
<1
<1
<1
Power consumption at
Standby (W)
6
6
6
6
6
6
6
Power Efficiency
Max.Efficiency
98.03%
98.03%
98.03%
98.03%
98.03%
98.03%
98.03%
Euro Efficiency
97.60%
97.60%
97.60%
97.60%
97.60%
97.60%
97.60%
MPPT Efficiency
＞99.9%
＞99.9%
＞99.9%
＞99.9%
＞99.9%
＞99.9%
＞99.9%
Safety and protection
Safety Standard
EN/IEC 62109-1/-2
EMC Standard
EN/IEC 61000-6, EN/IEC 61000-3
Anti-islanding Protection
Intenal
General information
Dimensions (H×W×D) [mm]
460*345*170
560*345*170
Enclosure
IP65
Pollution degree
3
UV protection
Aluminium
RCD
Internal
Weight [kg]
17
18.5
Ambient Temperature Range
-25℃ ~ +60℃
Humidity range
0% ~ 100%
Topology
Transformerless
Communication Interface
RS485/WI-FI/Wire Ethernet/GPRS (optional)
Cooling Concept
Convection
Noise Emission [dB]
＜40
Elevation
Up to 4000m without derating

Afore HNS TL-1 Series Specifications

General

Brand	Afore
Model	HNS TL-1 Series
Category	Inverter
Language	English
