7
② 1 set applies to HNSxxxxTL-1 (xxxx=1000, 1500, 2000, 2500, 3000,3600);
2 sets apply to HNSxxxxTL (xxxx=3000, 3600, 4000, 5000,6000,7000,8000)
3.2 Identifying the Inverter
You can identify the inverter by the type label. Information such as serial number (Serial No.) and model
name of the inverter, as well as the device’stechnical parameters are specified on the type label. The type
label is on the right side of the enclosure.
4 Mounting
4.1 Safety
DANGER!
Danger to life due to potential fire or electric shock.
Do not install the inverter near any inflammable or explosive items. The inverter will be directly connected
with high voltage power generation device. The installation must be performed by qualified personnel only
in compliance with national or local standards and regulations.
CAUTION!
Danger of burn injuries due to hot enclosure parts.
•Install the inverter so that it cannot be touched inadvertently.
Risk of injury due to the heavy weight of the inverter.
• Take the inverter's weight into account for mounting.（Weight of inverter refers to chapter 9.）
4.2Selecting the Appropriate Mounting Location
Consider the following points when selecting where to install:
• The mounting method and location must be suitable for the inverter's weight and dimensions.
• The inverter must be installed in the solid walls ,such as brick walls or concrete walls,in case of vibration
noise or inverter falling off.
• The installation site should be clearly visible and can be safely into without aids such as scaffold.
• For the convenience of checking the LCD display and possible maintenance activities, please install the
inverter at eye level.
