AFRISO DTA 10 - Mounting the mounting kit for battery tanks Pneum. (optional)

17
Mounting
EN
DTA 10
5.5 Mounting the mounting kit for battery tanks "Pneum." (optional)
Depending on the manufacturer, battery tanks have one or more plastic
flanges (A). The plastic flanges are provided for filling, venting or withdrawal.
The mounting kit is installed in one of the plastic flanges (A).
A. Plastic flange
A. Connection piece with
conical thread
B. Hose
C. Weight Ø 9 mm
A
C
A
B
