18
Mounting
EN
DTA 10
1. Check whether the plastic flange of the battery tank has a hole Ø 10 mm
to Ø 10.5 mm which is closed by means of a blind plug.
2. Remove the blind plug.
3. Push the weight (C) and the hose (C) through the hole.
4. Screw the connection piece (A) into the hole.
If the plastic flange does not have a hole, proceed as follows:
1. Dismount the plastic flange.
2. Drill a vertical hole Ø 10 mm through the plastic flange.
3. Remount the plastic flange.
4. Push the weight (C) and the hose (C) through the hole.
5. Screw the connection piece (A) into the hole.
