Commissioning
EN
DTA 10
6.2.2 Adjusting the medium
You can select one of the following liquids:
• Water (density 1 g/cm³)
• Fuel oil (density 0.84 g/cm³)
• Variable (density adjustable from 0.5 - 1.5 g/cm³)
6.2.3 Setting the tank shape
If the geometry of the tank differs from the geometries listed, the informa-
tion must be taken from the bearing chart of the tank manufacturer.
You can select one of the following tank shapes:
• Linear
• Ball
• Horizontal cylinder
6.2.4 Adjusting the tank height
You can select the following values:
• 0 cm to 400 cm
Adjusting a higher liquid level (for example 180 cm):
1. Press the upper or lower key (individual steps) or hold down the corre-
sponding key until you have set the required liquid level.
6.2.5 Adjusting the tank volume
You can select the following values:
• 0 litres to 99999 litres
1. Press the upper or lower key (individual steps) or hold down the corre-
sponding key until you have set the required tank volume.
6.2.6 Adjusting the alarm
You can select the following values:
• 0 % to 100 %
1. Press the upper or lower key (individual steps) or hold down the corre-
sponding key until you have set the required percentage.
