AG-NAV Granular Flow Controller - 1: Getting Started; About Ag-Nav Granular Flow Controller; Parts List; Before Installation

AG-NAV 1-800-99 AGNAV
5
1: Getting started
1.1 About Ag-Nav granular flow controller
The Ag-Nav Granular Flow Controller works in conjunction with the Isolair 4500 series Broadcaster
system to provide even application of granules over the target areas. The Granular Flow Controller
consists of one controller box, two granular dispensers and harness. Each granular dispenser has an
impeller driven by a covered DC motor with a RPM encoder.
1.2 Parts list
Before Installation, please check that all components are included in the package (shown below)
Components
Part No.
Quantity
Weight (Lbs)
DUAL GRANULAR SYSTEM
AAP8300-DUAL
1
16.48
NOTE: INCLUDES 2 X HOUSINGS WITH IMPELLERS / 2 X
MOTORS WITH ENCODERS AND MOTOR COVERS
HOUSINGS.
UNIFIED FLOW CONTROLLER MODULE (Granular
mode)
AAP188-A
1
0.80
DUAL GRANULAR UFC CONTROLLER HARNESS
AC0188-A/B
1
2.70
GRANULAR FLOW CONTROLLER INSTALLATION
GUIDE
CD/MANUAL
1
.01
INCLUDED FASTNERS
FLAT SOCKET CAP M5 X 20M (MOTOR BRACKET)
Prod-s-fs-5m-
20mm
4
0.20
SOCKET CAP M10 X 25MM (HOUSING FASTNER)
Prod-s-c-10mm-
25mm
8
1.3 Before installation
Before you begin installation, please make sure to carefully read the installation instructions. If any
questions arise, please contact Ag-Nav customer support. Contact information is located on page 3 of
this manual.
