AGA Ellesmere Standard Gas Stove 31
AGA Flue Kit 3 – Rear Exit
Please Note – The Maximum length of the Horizontal flue is 500mm as per the drawing above
Diagram for illustration purposes only - Not to Scale
This rear kit is called a Snorkel, this can only be used when the stove is being fitted to an outside wall,
the horizontal pipe can be no longer than 500mm long (this pipe is telescopically adjustable)
For this you need to fit the 2 x flue collars onto the rear of the stove, and move the 2 x blanking plates to
the top of the stove, you will also need to order from spares a blanking plate for the top plate lid of the
stove
To Order Flue kits please email Spares@agastoves.org.uk or ring Poujoulat on 01483 461700
Flue Kit 3 – Consists of the following:
Snorkel Terminal Flue Pipe – Horizontal
flue is adjustable in length from 350mm to
550mm
Use only for rear exit installation on an outside
wall
AGA Part Number:
AE4M 531087 - Matt Black Finish (RAL 9030)
Only available in Matt Black
