DR 10e, DR 14e, DR 17e Power Box
Model 6011/107
Original model number PB-DRE-001
Dimensions
Dimensions (width x height x depth) 259 mm x 70 mm x 205 mm
Weight
3.2 kg
Electrical connection
Rated Power Supply 100-240 V AC, 2-0.84 A, 50-60 Hz
Environmental conditions (during normal operation)
Room temperature between 15 °C and 35 °C
Humidity (non condensing) between 15% and 80% RH
(non-condensing)
Atmospheric pressure between 700 hPa and 1060 hPa
Environmental conditions (power can be supplied, no normal opera-
tion)
Room temperature between 5 °C and 35 °C
Humidity (non condensing) between 10% and 80% RH
(non-condensing)
Atmospheric pressure between 700 hPa and 1060 hPa
Environmental conditions (storage)
Room temperature between -30 °C and 50 °C
Humidity (non condensing) between 10% and 90% RH
(non-condensing)
Atmospheric pressure between 700 hPa and 1060 hPa
120 | DR 10e, DR 14e, DR 17e | Technical Data
0370C EN 20200228 1449
