AGFA Drystar 5300 - Cleaning the Print Head Resistor Line

60
2921B EN 20031206
Cleaning the print head resistor line
To clean the print head:
1 Press the Key-operator key to enter the key-operator mode.
2 On the key-operator main menu, press the Down key five times, followed by
the Confirm key to select ‘Calibration’.
3 On the Calibration menu, press the Down key, followed by the Confirm key to
select ‘Therm. Head clean.’.
The printer will automatically shut down:
4 The ‘Thermal head cleaning’ screen will give step by step instructions on
what to do:
Print head cleaning must be done when image quality problems occur.
For more information on maintaining image quality, refer to ‘Image
quality problems’ on page 186 of the Drystar 5300 Reference manual.
1 Show settings
2 Change settings
3 Print image
4 Save configuration
5 Restore config.
6 Calibration
7 Service actions
8 Quality control
9 Installation
KO
CA
SELECT
CALIBRATION
1 film calibration
2 Therm. Head clean.
THERMAL HEAD
CLEANING
- Open top cover
CA
