Icon Description
The image is planned as a free exposure using the Portable
DR detector.
The image is planned as a free exposure.
The type and configuration of the X-ray system defines which modality
positions are available.
Note: The modality position of a U-Arm X-ray system is represented
by the icon for a radiographic table.
The modality position icon indicates the status of the DR detector.
Table 2: DR detector status
Icon
Status description
Grey: the image is planned and the DR detector is in sleep
mode.
Green: the DR detector is ready to acquire the exposure on
the selected acquisition system.
Green flashing: the exposure has been performed and the
acquisition is ongoing.
Red: the DR detector is out of order.
Red flashing: the selected acquisition system is starting up.
The available workstations depend on the modality type and configuration.
24 | DX-D Software Console | Operating the DX-D Software Console
0189D EN 20180329 1421
