Figure 14: Sensitivity
Density
These buttons are used to adjust the AEC cut-off dose (and patient entrance
dose accordingly).
Figure 15: Density
Density can be increased and decreased in a range of -4 to +4. Each step gives
a difference of 25% in dose (25% is the default setting). When disabled, the
density range number appears in black.
Table 9: Density scale variation over reference dose (0)
Density
-4 rd x 0.41
-3 rd x 0.51
-2 rd x 0.64
-1 rd x 0.80
0 Reference dose (rd)
+1 rd x 1.25
+2 rd x 1.56
+3 rd x 1.95
+4 rd x 2.44
Patient Size
The size of the patient is classified in five categories: Extra Small, Small,
Medium, Large and Extra Large.
Touch the UP or DOWN arrows to select the desired patient size.
38 | DX-D Software Console | Operating the DX-D Software Console
0189D EN 20180329 1421
