Agilent 1290 Infinity Pump Service Kit 5
Disassembling the Primary Pump Head
Figure 1 Pump Head (with seal wash option)
1 Pump head chamber housing
2 Pump seal
3 Backup ring for seal holder
4 Seal holder
5 Film washer (seal wash)
6 Backup seal PE for seal wash
7 Support ring (seal wash)
8 Pump head ferrule
9 Piston housing
10 Piston
1
2
3
4
5
6
7
8
9
10
