Agilent Technologies 16900 Series Service Guide

116
Chapter 6: Replacing Assemblies
3 Remove the logic analyzer cable.
a Gently lift the logic analyzer cable end connector from the circuit board
connector (J1, J2, J3, or J4).
4 If the logic analyzer cable is faulty, replace the cable and follow the next
procedure to install the replacement logic analyzer cable.
