Chapter 3: Testing Logic Analyzer Performance
Equipment Required
Equipment Required
The following equipment is required for the performance test procedure.
Equipment Required
Equipment Critical Specification Recommended Model/Part
Pulse Generator ≥ 310 MHz, two channels,
differential outputs, 150-180 ps
rise/fall time (if faster, use
transition time converters)
Agilent or HP 8133A option 003
150 ps Transition Time
Converter
(Qty 4)
Required if pulse generator’s rise
time is less than 150 ps. (Pulse
generator conditions: Voffset=1V,
∆V=250 mV.) Required for 8133A
opt. 003.
Agilent or HP 15435A
Oscilloscope bandwidth ≥ 1.5 GHz,
sampling rate ≥ 8 GSa/s
Agilent or HP 54845A/B or
similar
SMA Coax Cable
(Qty 2)
>18 GHz bandwidth Agilent or HP 8120-4948
Flying Lead Probe Set
(Qty 2)
no substitute Agilent E5382A
Male BNC to Female SMA
adapters
(Qty 2)
Cambridge Products CP-AD507
(see
www.cambridgeproducts.com)
SMA/Flying Lead test
connectors, (f) SMA to (f)
SMA to Flying Lead Probe
(Qty 4)
no substitute See “Assemble the SMA/Flying
Lead Test Connectors” on
page 23
