Chapter 3: Testing Logic Analyzer Performance
Test Pods 3 and 4 in 600 Mb/s Mode
Test Pods 3 and 4 in 600 Mb/s Mode
1 Perform the normal and complement tests for each additional pod on the
logic analyzer, changing the connection to the pod, channel assignments,
thresholds, etc. as appropriate. You must use the J clock on Pod 1 for all
tests in the 600 Mb/s mode because the other clocks are not available in
this mode. Upon completion, the logic analyzer is completely tested.
2 Complete the Performance Test Record on page 86.
Conclude the State Mode Tests
Do the following steps to properly shut down the logic analyzer session after
completing the state mode tests.
1 End the test.
a In the Logic Analysis System window, select the [X] in the upper right
corner to close the window. At the query, select OK.
Ending and restarting the logic analysis session will re-initialize the system.
b Disconnect all cables and adapters from the pulse generator and the
oscilloscope.
