Agilent Technologies 4263B Configuration Guide

5
Available Accessories – General Measurement Accessories – continued
Description Model Number
Requires
(Instrument
must already
include the
following)
Additional Information
Alligator Clip Leads 16089D None 4 medium clips; cable length 1 m. Operation and
Service Manual is furnished.
Kelvin Clip Leads 16089E None 2 large clips; cable length 1 m. Operation Note
is furnished.
4-Terminal to 7 mm Coaxial
Adapter
16085B None Terminal converter for using RF component test
fi xture such as the 16092A, 16192A, 16194A,
16196A/B/C/D and 16197A. Operation Note is
furnished.
Dielectric Test Fixture 16451B None Test fi xture for measuring permittivity of dry solid
sheet material; Cable length 1 m. 38 mm and 5 mm
diameter electrodes for measuring bare material
and two types of electrodes for measuring material
with pre-formed electrodes are furnished.
16451B-ABA None U.S. - English localization
16451B-ABJ None Japan – Japanese localization
Liquid Test Fixture 16452A None
(16048A or
16452-61601
Test Leads
recommended)
Test fi xture for measuring permittivity of liquid
material. Required volume of material; 3.4, 3.8, 4.8
or 6.8 ml. Temperature range: –20 ° to +125 °C.
Shorting plate, spacers, SMA-BNC adapters, fi xture
stand, carrying case and Operation and Service
Manual are furnished.
Test Leads 16452-61601 None Heat-proof test leads for use with the 16452A.
Temperature range: –20 ° to +125 °C
3-Terminal SMD Test
Fixture
16043-60011 None Equivalent to previous 16043A. For related options
and accessories, see Note below this table.
3-Terminal SMD Test
Fixture
16043-60012 None Equivalent to previous 16043B. For related options
and accessories, see Note below this table.
Balanced/Unbalanced 4-
Terminal Converter
16314-60011 None Equivalent to previous 16314A; Unbalanced 50 Ω
to balanced 50 Ω converter for measuring balanced
device or circuit. Shorting bar and 50 Ω resistor
for Short/Load compensation and Operation and
Service Manual are furnished.
Note: For more detailed information, refer to Accessories Selection Guide for Impedance Measurements.
