6
Available Accessories – External DC Bias Accessories
Description Model Number
Requires
(Instrument
must already
include the
following)
Additional Information
External Voltage Bias Fixture 16065A None ±200 V dc max., for axial or radial lead device.
Shorting plate and Operation and Service
Manual are furnished.
External Bias Adapter 16065C None External DC bias adapter; ±40 V dc max., 100 Hz
to 1 MHz. Compatible with all the test fi xtures,
test leads and clip leads except for the 16060A.
Operation and Service Manual is furnished.
Note: For more detailed information, refer to Accessories Selection Guide for Impedance Measurements
Available Accessories – for Calibration and Maintenance
Description Model Number
Requires
(Instrument
must already
include the
following)
Additional Information
Open Termination 42090A None 4-terminal pair Open termination. Needed for
performing calibration.
Short Termination 42091A None 4-terminal pair Short termination. Needed for
performing calibration.
4-Terminal Pair Standard
Capacitor Set
16380A None 1 pF, 10 pF, 100 pF and 1000 pF standard
capacitor set with carrying case. Calibration
report and Operation Note are furnished.
4-Terminal Pair Standard
Capacitor Set
16380C None 0.01 μF, 0.1 μF and 1 μF standard capacitor
set with carrying case. Calibration report and
Operation Note are furnished.
16380C-001 None Adds 10 μF standard capacitor
4-Terminal Pair Standard
Resistor Set
42030A None 9 standard resistors from 1 mΩ to 100 kΩ
in decade steps; Carrying case, calibration
report and Operation and Service Manual are
furnished.
Note: For more detailed information, refer to Accessories Selection Guide for Impedance Measurements
