Agilent 5890 3 Installation Procedure
3.5 Clarity Configuration
Fig 4: System Configuration
Start the Clarity station by clicking on the icon on the desktop.
Invoke the System Configuration dialog accessible from the Clarity
window using the System - Configuration... command.
Press the Add button ① (see Fig 4 on pg 7.) to invoke the Available
Control Modules dialog.
You can specify the searching filter ② to simplify the finding of the driver.
Select the 5890 and press the Add ③ button.
- 7 -
