Agilent 5890 3 Installation Procedure
3.3 Description of connectors:
Signal 1 (2)
12-pin HP connector with output of both analog amplifiers (connected to
detector).
It is possible to plug in both orientations with same function.
Note: Not necessary when using the digital acquisition.
Remote
12-pin HP connector dedicated to send start signal to Clarity
It is necessary to plug it in proper position according to mark on cable
connector
Not necessary when using digital acquisition
INET
INET loop cable. In case of newer INET cards provided by DataApex
company, no loop cable is needed. The cable connection is replaced by
wiring on the back side of the card.
RS232
25-pin female Cannon connector for direct control and digital acquisition
- 5 -
