Agilent Technologies 6624A Operating Instructions

12
Table 3. FLT/INH/RLY Replaceable Parts List
REF. DES. PART NUMBER DESCRIPTION
C701 01604830 Cap, 2200pF 10% 100V
C702 0160-4281 Cap, 2200pF 20% 250V
C703-706 01604835
Cap, 0.1µF 10% 50V
C707-710 01604801 Cap, 100pF 5%100V
C711-714 01604834
Cap, 0.047µF 10%100V
C715-717 01604835
Cap, 0.1µF 10% 50V
CR701-704 1901-0050 Diode, SW 80V 200mA
CR705-708 1901-0937 Diode, 11DQ Schottky
J701 1252-1152 Connector, 10-pin
J702 1252-1488 Connector, 4-pin
1252-1853 Plug (Ref J702)
J703 1252-1864 Connector, 8-pin
1252-1854 Plug (Ref J703)
R701-703 0686-1015 Fix comp 100 5%1/2W
R704 0683-1215 Fix comp 1.21K 1%1/8W
R705 0698-3446 Fix comp 383 1% 1/8W
R706 0757-0401 Fix comp 100 1% 1/8W
R707-710 0757-0438 Fix comp 5.11K 1% 1/8W
R711-714 0757-0442 Fix comp 10K 1% 1/8W
R715-718 0698-3450 Fix comp 42.2K 1% 1/8W
R719-722 0757-0481 Fix comp 475K 1% 1/8W
R723-726 0683-1215 Fix comp 1.21K 1% 1/8W
R727-730 0757-0442 Fix comp 10K 1% 1/8W
R731-734 0698-8816 Fix comp 2.15K 1% 1/8W
R735 0683-2255 Fix comp 2.2M 5% 1/4W
U701 1990-0543 Opto-isolator
U702 1826-0065 Voltage Comparator, LM311
U703,704 1820-3673 Monostable Multivibrator, HC123
U705 1826-0138 Voltage Comparator
U706 1855-0591 Quad MOSFET
VR701 1902-0556 Zener, 20V 5% 1W IR = 5mA
VR702 1902-0049 Zener, 6.19V 5% 0.4W
VR703-706 1902-0176 Zener, 47V
W17 5080-2212 Ribbon Cable
9170-1497 Core-shield bead
06624-60025 Option 750 Circuit Board
06624-60026 GPIB Board
06624-61025 Tested Option 750 Board
Cover Plate
0515-1146 Mounting screws
0380-1361 Standoffs
06621-81004 6621A Label
06622-81004 6622A Label
06623-81004 6623A Label
06624-81004 6624A,Label
