Language Dictionary - 8
113
[SOURce:]CURRent:TRIGger
This command sets the pending triggered current level of the dc source. The pending triggered level is a
stored current value that is transferred to the output terminals when a trigger occurs. In order for a trigger
to occur, the trigger subsystem must be initiated (see the INITiate command in the trigger subsystem).
Command Syntax
[SOURce:]CURRent[:LEVel]:TRIGgered[:AMPLitude] <NRf+>
Parameters
see Table 8-3
Default Suffix
A ( amperes)
*RST Value
10% of MAX
Examples
CURR:TRIG 1CURRENT:LEVEL:TRIGGERED 1
Query Syntax
SOURce:]CURRent[LEVel]:TRIGgered[:AMPLitude]?
Returned Parameters
<NR3>
[SOURce:]CURRent2:TRIGger
Agilent 66319B/66319D only
This command sets the triggered current level of the auxiliary output. The triggered level is a stored
value that is transferred to the output when a trigger occurs. In order for a trigger to occur, the trigger
subsystem must be initiated (see the INITiate command).
Command Syntax
[SOURce:]CURRent2[:LEVel]:TRIGgered[:AMPLitude] <NRf+>
Parameters
see Table A-3
Default Suffix
A ( amperes)
*RST Value
10% of MAX
Examples
CURR2:TRIG 1 CURR2:LEV:TRIG 1
Query Syntax
SOURce:]CURRent2[LEVel]:TRIGgered[:AMPLitude]?
Returned Parameters
<NR3>
[SOURce:]DIGital:DATA
This command programs the digital control port when the port is configured for Digital I/O operation.
The port has three signal pins and a digital ground pin. Pins 1 and 2 are output pins controlled by bits 0
and 1. Pin 3 is controlled by bit 2, and can be programmed to serve either as an input or an output. It
normally serves as an output. Bit 2 must be programmed high to use pin 3 as an input. Pin 4 is the digital
ground. Refer to the following chart for list of the programmable pin settings. The query returns the last
programmed value in bits 0 and 1, and the value read at pin 3 in bit 2.
Program
Value
Bit
Configuration
2 1 0
Pin Setting
4 3 2 1
0 0 0 0 GND Output Lo Lo
1 0 0 1 GND Output Lo Hi
2 0 1 0 GND Output Hi Lo
3 0 1 1 GND Output Hi Hi
4 1 0 0 GND Input Lo Lo
5 1 0 1 GND Input Lo Hi
6 1 1 0 GND Input Hi Lo
7 1 1 1 GND Input Hi Hi
