Language Dictionary - 8
133
*RCL
This command restores the dc source to a state that was previously stored in memory with the *SAV
command to the specified location. All states are recalled with the following exceptions:
$ the trigger system is set to the Idle state by an implied ABORt command (this cancels any
uncompleted trigger actions)
$ the calibration function is disabled by setting CAL:STATe to OFF
NOTE: The device state stored in location 0 is automatically recalled at power turn-on when the
OUTPut:PON:STATe is set to RCL 0.
Command Syntax
*RCL <NRf>
Parameters
0 | 1 | 2 | 3
Example
*RCL 3
Related Commands
*PSC *RST *SAV
*RST
This command resets the dc source to a factory-defined state as defined in the following table. *RST also
forces an ABORt command.
Table 8-7. *RST Settings
CAL:STAT OFF [SOUR:]CURR2 10% of MAX
DIG:DATA 0 [SOUR:]CURR2:TRIG 10% of MAX
DISP:STAT ON [SOUR:]CURR:PROT:STAT OFF
DISP:MODE NORM [SOUR:]LIST:COUN 0
DISP:TEXT “ “ [SOUR:]VOLT 0
INIT:CONT OFF [SOUR:]VOLT:LIM 15 V0
INST:COUP:OUTP:STAT ALL [SOUR:]VOLT:TRIG 0
NONE (option 521 units) [SOUR:]VOLT2 0
OUTP OFF [SOUR:]VOLT2:LIM 12 V
OUTP:COMP HREMOTE [SOUR:]VOLT2:TRIG 0
OUTP:DFI OFF [SOUR:]VOLT:PROT MAX
OUTP:DFI:SOUR OFF [SOUR:]VOLT:PROT:STAT ON
OUTP:PROT:DEL .08 TRIG:ACQ:COUN:CURR 1
OUTP:PROT:STAT OFF TRIG:ACQ:COUN:VOLT 1
OUTP:RELay HH TRIG:ACQ:HYST:CURR 0
SENS:CURR:RANG 3A TRIG:ACQ:HYST:DVM 0
SENS:CURR:DET ACDC (all but 66321A) TRIG:ACQ:HYST:VOLT 0
DC (66321A only) TRIG:ACQ:LEV:CURR 0
SENS:FUNC VOLT TRIG:ACQ:LEV:DVM 0
SENS:SWE:OFFS:POIN 0 TRIG:ACQ:LEV:VOLT 0
SENS:SWE:POIN 2048 TRIG:ACQ:SLOP:CURR POS
SENS:SWE:TINT 15.6 µs
TRIG:ACQ:SLOP:DVM POS
[SOUR:]CURR 10% of MAX TRIG:ACQ:SLOP:VOLT POS
[SOUR:]CURR:TRIG 10% of MAX TRIG:ACQ:SOUR INTERNAL
TRIG:TRAN:SOUR BUS
NOTE: You can change the factory default *RST settings for the OUTput COMPensation,
COUPling, RELay, and PROTection parameters. Refer to Appendix B for details.
Command Syntax
*RST
Parameters
None
Related Commands
*PSC *SAV
