102 Replaceable Parts
Table 5-9. A5 Control Board Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C750,751 (Model specific)
6571A, 6671A (Not used)
6572A, 6672A 0160-4829 Capacitor 680pF 10%
6573A, 6673A,
6574A, 6674A
0160-4822 Capacitor 1000pF 5%
6575A, 6675A 0160-0178 Capacitor 470pF 5%
C760 0160-4788 Capacitor 18pF 5% 100V
C851 0160-4835
Capacitor 0.1µF 10% 50V
C852 0160-4183 Capacitor 1000pF 20%
C855 0160-5098
Capacitor 0.22µF 10%
C885,894,895 0160-4835
Capacitor 0.1µF 10% 50V
C892,893 0180-4136
Capacitor 10µF 20V
C896 0160-4183 Capacitor 1000pF 20%
C899 0160-4835
Capacitor 0.1µF 10% 50V
C900 0160-4801 Capacitor 100pF 5%
D530 1901-1098 Diode 1N4150
D605,610-613,615 1901-1098 Diode 1N4150
D618 1901-0880 Diode GEN PRP
D620,621,626,627,630,631,
641
1901-1098 Diode 1N4150
D651 1901-0880 Diode GEN PRP
D660,661 1901-1098 Diode 1N4150
D662-665 1901-0880 Diode GEN PRP
D666-668 1901-1098 Diode 1N4150
D676 1901-0880 Diode GEN PRP
D677 1901-1098 Diode 1N4150
D678 1901-0880 Diode GEN PRP
D679,680 1901-1098 Diode 1N4150
D685 1901-0880 Diode GEN PRP
D686 1901-1098 Diode 1N4150
D687 1901-0880 Diode GEN PRP
D688,689 1901-1098 Diode 1N4150
D690-692 1901-0731 Diode PWR RECT
D693 1901-0880 Diode GEN PRP
J501 1252-3693 Connector
J502 1251-7330 Receptacle modular phone
J503 1252-0055 Connector POST-TP HDR
J509 1252-1992 Connector POST-TP-HDR
J510 1251-8666 Connector POST-TP
L001 9140-0158
Inductor lµH 10%
Q602 1853-0510 Transistor PNP
R501 0698-3456 Resistor 287K 1%
R502 1810-0305 Resistor network SIP
R504 (Model specific)
6571A, 6671A 0757-0123 Resistor 34.8K 1%
6572A-6574A,
6672A-6674A
0698-6983 Resistor 20.4K 0.1%
6575A, 6675A 0699-1212 Resistor 19K 0.1%
