94 Replaceable Parts
Table 5-6. A2 GPIB Board Replaceable Parts (see Note)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C122 0180-4606
Capacitor 10,000µF
C128 0160-4281 Capacitor 2,200pF
F101 2110-0699 Fuse Subminature 5AM
J101 1252-2320 Connector Receptacle (GPIB)
J106 1251-4926 Connector Receptacle (Test Header)
J107 1251-7330 Connector Receptacle
J108 1251-7330 Connector Receptacle
J114 1251-7330 Connector Receptacle
J115 1251-7330 Connector Receptacle
P101 1251-4245 Connector Plug 2-pin (AC Bias)
U110, U111 1990-0444 IC Optoisolator
U113 1990-0543 IC Optoisolator
U117 1820-2549 IC Optoisolator
U118 1820-4185 IC Optoisolator
U121 1820-0430 IC Voltage regulator
TB101 0360-2312 Terminal Block (Digital Control)
MECHANICAL PARTS
-- 1205-0758 Heatsink (U121)
-- 0535-0031 Nut hex w/lockwasher (J101)
-- 0515-0642 Screw (U121)
-- 0515-0911 Screw M3x0 5 (J101)
Note: All other parts are surface mounted and are not field repairable
