96 Replaceable Parts
Table 5-8. A4 AC Input Board Replaceable Parts
Ref
. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C304 0160-4834
Capacitor .047µF 10%
C305 0180-3458
Capacitor 4700µF 50V
C306,307 0180-4129
Capacitor 1µF 35V
C309 0180-4136
Capacitor 10µF 20V
C310 0160-4834
Capacitor .047µF 10%
C311 0180-3458
Capacitor 4700µF 50V
C312 0180-3587
Capacitor 1000µF 50V
C313-315,317,318 0180-4129
Capacitor 1µF 35V
C320,322 0180-4131
Capacitor 4.7µF 35V
C351 0180-3458
Capacitor 4700µF 50V
C352-354 0180-0230
Capacitor 1µF 50V
C357 0160-4554
Capacitor .01µF 20%
C358,359 0160-4835
Capacitor 0.1µF l0% 50V
C360,361 0180-3587
Capacitor 1000µF 50V
C420,421,423 0160-7606
Capacitor 1µF @250V
C425,426 0160-4439 Capacitor 4700pF
C427 0160-4065
Capacitor 0 1µF
C430 0160-4355
Capacitor 0.01µF 10%
C431 0160-4065
Capacitor 0.1µF
C497,498 0160-7606
Capacitor 1µF 250V
CR402 1990-0517 LED visible
D306-310,312-317 1901-0731 Diode, power rectifier
D318,319 1901-1098 Diode 1N4150
D400 1906-0389 Diode, full-wave bridge
E403,404,411,412 1251-5613 CONN-SGL CONN
F304 2110-0304 Fuse 1.5AT 250V
F308 2110-0202 Fuse 0.5AT 250V
F400 2110-0849 Fuse 25AM 250V
F401 2110-0098 Fuse 20AM 250V
FL1 (see Table 5-3)
J301,302,40p 1252-0055 Connector-POST-TP HDR
J500 1251-8837 Connector-POST-TP-HDR
K400,401 0490-1746 Relay lC 30A @ 30Vdc, 15Vdc coil
L402 06012-80095 Inductor, output choke
R315 0698-8672
Resistor 243.4 Ω O 1%
R316 0698-0085 Resistor 2.61K 1%
R317 8159-0005
Resistor 0 Ω
R326 0698-8672
Resistor 243.4 Ω 0.1%
R327 0757-0281 Resistor 2.74K 1%
R328 0757-0281 Resistor 2.74K 1%
R329 0698-8672
Resistor 243.4 Ω 0.1%
R330,331 8159-0005
Resistor 0 Ω
R332 0764-0041
Resistor 30 Ω 5% 2W
R333 8159-0005
Resistor 0 Ω
R339 0698-3155 Resistor 4.64K 1%
R350 0757-0434 Resistor 3.65K 1%
