Agilent Technologies 6674A - Page 99

Replaceable Parts 99
Table 5-9. A5 Control Board Replaceable Parts
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C501 0160-5422
Capacitor 0.047µF 20%
C502,503 0160-4805 Capacitor 47pF 5% 100V
C504 0160-5422
Capacitor 0.047µF 20%
C505 0180-4129
Capacitor 1µF 35V
C507,509 0160-5422
Capacitor 0.047µF 20%
C510 0160-4801 Capacitor 100pF 5%
C512 0160-5422
Capacitor 0.047µF 20%
C513 0160-4801 Capacitor 100pF 5%
C515 0160-5422
Capacitor 0.047µF 20%
C516 0160-4801 Capacitor 100pF 5%
C515,517,518 0160-5422
Capacitor 0.047µF 20%
C519 0180-4129
Capacitor 1µF 35V
C520,521 0160-5469
Capacitor 1µF 10% 50V
C523 0160-4846 Capacitor 1500pF 100V
C524 0160-5422
Capacitor 0.047µF 20%
C530 0180-4129
Capacitor 1µF 35V
C531,532 0160-5422
Capacitor 0.047µF 20%
C533 0180-4131
Capacitor 4.7µF 35V
C550-555 0160-4835
Capacitor 0.1µF 10% 50V
C556-558 0180-4129
Capacitor 1µF 35V
C600 0180-4131
Capacitor 4.7µF 35V
C601 0160-4835
Capacitor 0.1µF 10% 50V
C602 0160-4805 Capacitor 47pF 5% 100V
C603,604 0160-4810 Capacitor 330pF 5%
C610 0160-4807 Capacitor 33pF 5% 100V
C620 0160-4904 Capacitor 6800pF 5%
C621 0160-4791 Capacitor 10pF 5% 100V
C622 0160-4795 Capacitor 4.7pF
C623 0160-4904 Capacitor 6800pF 5%
C624 0160-4787 Capacitor 22pF 5% 100V
C625 0160-4795 Capacitor 4.7pF
C626 0180-4129
Capacitor 1µF 35V
C630 (Model specific)
6571A-6573A,
6671A-6673A
0160-4801 Capacitor 100pF 5%
6574A, 6575A,
6674A, 6675A
0160-4787 Capacitor 22pF 5%
C631 0160-4799 Capacitor 2.2pF
C632 (Model specific)
6571A-6573A,
6671A-6673A
0160-4801 Capacitor 100pF 5%
6574A, 6575A,
6674A, 6675A
0160-4787 Capacitor 22pF S%
C655 (Model specific)
6571A-6574A,
6671A-6674A
0160-4831 Capacitor 4700pF 10%
6575A, 6675A 0160-4819 Capacitor 2200pF 5%
