General Information 29
Table 1-3b. Supplemental Characteristics for Series 667xA (continued)
1
Parameter All Models
Digital Port Characteristics
(see Table 1-5)
GPIB Interface Capabilities
(see Table 1-5)
Serial Link Capabilities
(see Table 1-5)
Recommended Calibration Interval:
1 year
Safety Compliance
Complies with:
Designed to comply with:
CSA 22.2 No.231,IEC 348
UL 1244
RFI Suppression (complies with):
CISPR-ll, Group 1, Class B
Dimensions
Width:
Height (including removable feet):
Depth (including safety cover):
425.5 mm (16.75 in)
145.1 mm (5.71 in)
640 mm (25.2 in)
Weight
Net:
Shipping:
27.7 kg (61 lb)
31.4 kg (69 lb)
Output Characteristic Curve:
Notes:
l
For Performance Specifications, see Table l-3a.
