Step 3: Rack Mount the Mainframe (Optional)
Note Simplified rack mount installation steps are shown here. Refer to the instructions provided
with the rack mount kits for specific details.
Refer to Appendix B for front handle/rack mount kit part numbers and typical
configurations.
C Secure mainframe to rack
A Install rails and flange nuts
B Attach rack mount hardware
Installing the System 1-5
