Agilent Technologies 7694 - Page 4

Maintaining the Instrument
Changing the Sampling Needle
4
Figure 18. Position of vial sampling needle
5. Replace the sampling needle, tighten the fittings, and perform a leak test
before replacing the insulation and cover.
Hexagonal union
Union
Sampling needle
Sampling needle
G1289/G1290 G1883
