Agilent Technologies B1500A Training Manual

Module 9
Modifying Application Test Definitions
9-12
To Modify Test Definition
Define Message box
Test Definition editor
This setup makes the OK button on
the message box.
This message box
asks you clicking the
OK button to display
the gm curve.
The value of the local
variable Yes is set to 1
from 0 by clicking the
OK button.
This setup displays the message
“To display the gm curve, click OK.”
on the message box.
Click the Message line in the program list. And define the message box.
This example defines the message box that opens after the Vth Const Id measurement and displays a
message and the OK button.
1. Enter the message.
2. Enter the button name.
3. Select the variable used to keep the status of the button.
4. Repeat 2 and 3 for all buttons you want to add.
