Agilent Technologies B1500A Training Manual

Module 9
Modifying Application Test Definitions
9-33
To Use Test Setup Internal Variables
From Display Setup screen
of Classic Test setup
Assign to external variables…
External Variable Setup
•Local variable
•Device parameter
•Test parameter
•Analysis parameter
Internal variable
From Application Test setup
Assign to external variables…
You may want to read the parameters/variables used in Classic Test setup or Application Test setup
defined in the Test Contents. Then use the External Variables Setup window used to make a
mapping table between the test setup internal variables/parameters and the external variables (local
variables, device parameters, test parameters, or analysis parameters).
To open the External Variable Setup window from a classic test setup:
•Specify the classic test.
•Click the Display Setup tab.
•Click the Assign to external variables… button.
To open the External Variable Setup window from an application test setup:
•Specify the application test.
•Click the Assign to external variables… button.
Note: Application test internal parameter/variable to be connected to an external variable must be the
analysis parameter in its test definition. For the analysis parameter, see “To Define Test Output” in
Module 10.
