Module 7
Measurement Functions
7-25
GM max
*
Early Voltage
Vth
Isub max
Hands-off marker
and line fitting
Auto Analysis
Auto analysis automates the task of doing scalar calculation on swept data. Computed parameters
such as Vth or GMmax can be displayed in the Parameters area on the Data Display window. The
built-in user functions allow data to be plotted and analyzed according to any arbitrary formula. The
B1500A has built-in functions such as axis intercepts, logs, regression lines, area integration,
max/min, and many more. The ability to automatically extract important parameters such as
threshold voltage without the need to manually manipulate screen cursors or markers is important in
process development.
