Agilent Technologies B1500A Training Manual

Module 7
Measurement Functions
7-16
z Monitor the charging voltage of an RC circuit
z Learn LOG10 data interval
z Learn how to properly define a sampling algorithm
z Use the instrument setup as same as the SMU pulse exercise
z Connect the RC components as shown in the next page
z Get and run the RC-sampling-log setup
z Change the range or ADC and perform append measurement
To Get Started:
You will:
Class Exercise
Sampling Measurement
