Module 7
Measurement Functions
7-15
z LINEAR
z Sampling interval: >= 2 ms
0.1 ms to 1.99 ms (limited)
z Number of samples: 1 to 100001
z LOG
z Sampling interval: >= 2 ms
z Number of samples: 1 + number of data for 11 decades
z Remaining data:
10/25/50/100/250/500 data are plotted into one decade
of the log scale in the same distance
I/V-t Sampling Measurement
There are two sampling mode. The linear sampling repeats the sampling in the specified interval
until the number of measurement data reaches the specified number of samples. High speed
sampling is available if the following conditions are satisfied. The high speed sampling allows
you to set the sampling interval 0.1 ms to 1.99 ms in 0.01 ms step.
1. Sampling mode is LINEAR
2. High speed ADC is used for all measurement channels
3. Interval >= 0.08 ms + 0.02 x (number of measurement channels) ms
The log sampling repeats the sampling in the specified interval and gathers the measurement data
which can be plotted on the log scale in the same distance. The sampling will be stopped when
the number of measurement data reaches the specified number of samples.
