Module 7
Measurement Functions
7-9
16442A/B Fixture
B1500A Rear View
SMU4
SMU3
SMU2
SMU1
CMU
GNDU
SMU Triax Connection
Force Lines to Fixture 1,2,3,4 Ports
This is the SMU cable setup that will be used in the remainder of the class exercises.
Connect the cables between the B1500A and test fixture as follows.
SMU1 : SMU1
SMU2 : SMU2
SMU3 : SMU3
SMU4 : SMU4
