Module 7
Measurement Functions
7-28
z Make a MOS threshold voltage (Vth) measurement
z Observe how parameters for the analysis are defined
z Observe how the user functions and analysis functions are
used in the analysis
z Use the standard MOS device and pin connections
z Get the GMMAX setup
z Make a measurement and turn the knob
z Click the Apply button to restore the analysis
To Get Started:
You will:
Class Exercise
Auto Analysis
In this exercise you will observe how auto analysis works. You will understand each setup screen
required to implement an auto analysis process.
