Agilent Technologies B1500A Training Manual

Module 7
Measurement Functions
7-37
z Measure 0.5 M ohm without Series Resistor
z Measure the same device with Series Resistor
z Learn how the Series Resistor works
z Use the instrument setup as same as the SMU pulse exercise
z Connect 0.5 M ohm as shown in the next page
z Get and run the IV-res setup
z Set the Series Resistor and perform Append measurement
To Get Started:
You will:
Class Exercise
SMU Series Resistor
