Service
DC Gain Accuracy Test
4-10
Figure 4-3
11
Press the
Meas
button on the front of the oscilloscope.
12
Select the
V
oltage
menu item.
Digital Multimeter
Power Supply
Oscillos
cope
BNC (f) to
dual
banana
BNC tee
105
107
