Automatic Measurement Controls
Voltage Measurements
2-56
Voltage Measurements
Pressing the Voltage menu button produces the following menus.
Table 2-25
Voltage Measurement Menu 1
Table 2-26
Voltage Measurement Menu 2
Table 2-27
Voltage Measurement Menu 3
Menu Comments
Voltage 1/3 Press to display menu 2 voltage measurements
Vpp Measure peak-to-peak voltage of a waveform
Vmax Measure maximum voltage of a waveform
Vmin Measure minimum voltage of a waveform
Vavg Measure average voltage of a waveform
Menu Comments
Voltage 2/3 Press to display menu 3 voltage measurements
Vamp Measure voltage between Vtop and Vbase of a waveform
Vtop Measure a flat top voltage of a waveform
Vbase Measure a flat base voltage of a waveform
Vrms Measure the root-mean-square voltage of a waveform
Menu Comments
Voltage 3/3 Press to display menu 1 voltage measurements
Overshoot Measure the overshoot voltage in percent
Preshoot Measure the preshoot voltage in percent
