Agilent Technologies E3614A User Manual

Table A-10. Replaceable Parts List
Reference Designator Agilen Part
Number
Q'ty Description Model Mfr. P/N Mfr.
Code
E3614A 1 60W BENCH POWER SUPPLY - E3614A MODEL
E3615A 1 60W BENCH POWER SUPPLY - E3615A MODEL
E3616A 1 60W BENCH POWER SUPPLY - E3616A MODEL
E3617A 1 60W BENCH POWER SUPPLY - E3617A MODEL
E3614-60005 1 MAIN BODY ASSY 14 28480
E3615-60005 1 MAIN BODY ASSY 15 28480
E3616-60005 1 MAIN BODY ASSY 16 28480
E3617-60005 1 MAIN BODY ASSY 17 28480
0371-3806 1 KEY CAP - WHT ALL 28480
0371-8624 1 KEY CAP - GRAY ALL 28480
E361X-60003 1 FRONT PANEL ASSY ALL 28480
E361X-60009 1 DISPLAY BOARD ASSY ALL 28480
R84,85 2100-4503 2 RES-VAR 10K 5% 10-TURN WW ALL 3590S-A17-103 32997
E3631-20011 1 BINDING POST RED ALL 28480
E3631-20012 1 BINDING POST BLACK ALL 28480
E3631-20013 1 BINDING POST GREEN ALL 28480
2950-0144 3 NUT- BINDING POST ALL 28480
5041-8621 2 KNOB ALL 28480
E3614-60002 1 MAIN BOARD ASSY 14 28480
E3615-60002 1 MAIN BOARD ASSY 15 28480
E3617-60002 1 MAIN BOARD ASSY 16 28480
E3617-60002 1 MAIN BOARD ASSY 17 28480
5021-8128 1 PCB MAIN FOR E3614A,E3615A 14,15 28480
5021-8139 1 PCB MAIN FOR E3616A,E3617A 16,17 28480
C1,3,47 0160-4835 3 CAP-FXD .1UF +-10% 50V CER X7R ALL 28480
C2 0180-4360 1 CAP-FXD 1000UF 25V +-20% AL-ELECTLT 14 28480
C2 0180-4355 1 CAP-FXD 470UF 50V +-20% AL-ELECTLT 15 28480
C2 0180-4452 1 CAP-FXD 330UF 63V +-20% AL-ELECTLT 16 28480
C2 0180-3595 1 CAP-FXD 220UF 100V +-20% AL-ELECTLT 17 28480
C4,5 0160-0269 2 CAP-FXD 0.1UF +-20% 500V CER Z5U ALL 28480
C6 0180-3990 1 CAP-FXD 4700UF +-20% 25V AL-ELECTLT ALL 28480
C7,8 0180-4567 2 CAP-FXD 39000UF 25V +-20% AL-ELECTLT 14 28480
C7,8 0180-4568 2 CAP-FXD 12000UF 63V +-20% AL-ELECTLT 15 28480
C7,8 0180-4607 2 CAP-FXD 5600UF 100V +-20% AL-ELECTLT 16 28480
C7,8 0180-4566 2 CAP-FXD 2700UF 160V +-20% AL-ELECTLT 17 28480
C9,41,42,43,55 0180-3970 5 CAP-FXD 1UF +-20% 50V AL-ELECTLT ALL 28480
C10,48,49 0160-7449 3 CAP-FXD 0.33UF +-10% 50V POLYE-FL ALL 28480
C11,16,17,25,26 0160-4832 5 CAP-FXD 0.01UF +-10% 100V CER X7R 14,15 28480
C12 0160-4835 1 CAP-FXD .1UF +-10% 50V CER X7R 14,15 28480
C13,14,15,30,32, 0160-4832 10 CAP-FXD 0.01UF +-10% 100V CER X7R ALL 28480
A-13
34,38,39,50,54
