Table A-10. Replaceable Parts List (Cont'd)
Reference Designator Agilent Part
Number
Q'ty Description Model Mfr. P/N Mfr.
Code
C18,21,24,27 0160-7077 4 CAP-FXD .1UF +-10% 630V POLYE-FL 14,15 28480
C19,22 0160-4822 2 CAP-FXD 1000PF +-5% 100V CER COG 14,15 28480
C20,23 0180-3970 2 CAP-FXD 1UF +-20% 50V AL-ELECTLT 14,15 28480
C28 0160-6225 1 CAP-FXD 0.33UF +-10% 250V POLYE-MET ALL 28480
C29 0160-4832 1 CAP-FXD 0.01UF +-10% 100V CER X7R 14,15 28480
C29 0160-7673 1 CAP-FXD .047UF +-10% 100V POLYP-MET 16,17 28480
C31 0160-7075 1 CAP-FXD 4700PF +-2% 50V POLYP-FL ALL 28480
56
0160-4822 6 CAP-FXD 1000PF +-5% 100V CER COG ALL 28480
C36 0160-7548 1 CAP-FXD 2200PF +-10% 50V CER Y5P ALL 28480
C37 0160-4801 1 CAP-FXD 100PF +-5% 100V CER COG ALL 28480
C40 1 CAP-FXD .047UF +-10% 100V POLYP-MET ALL 28480
C52 0180-4085 1 CAP-FXD 330UF +-20% 35V AL-ELECTLT ALL 28480
C53 0180-4355 1 CAP-FXD 470UF 50V +-20% AL-ELECTLT ALL 28480
C57 0180-4437 1 CAP-FXD 47UF +-20% 50V AL-ELECTLT ALL 28480
C58 0160-4065 1 CAP-FXD 0.1UF +-20% 250V PPR-MET ALL 28480
C59,60 0160-7049 2 CAP-FXD 4700PF +-20% 250V CER X5V ALL 28480
C61 0160-7363 1 CAP-FXD 1UF +-10% 250V POLYP-MET 16,17 28480
C62 0160-4808 1 CAP-FXD 470PF +-5% 100V CER COG 16,17 28480
C63,64,65,66 0160-0301 4 CAP-FXD 0.012UF +-10% 200V PE-FL 17 28480
R1,2 0811-3478 2 RESISTOR 0.1 +-1% 5W PWN TC=0+-90 14 28480
R1,2 0811-3839 2 RESISTOR 0.2 +-1% 5W PWN TC=0+-90 15 28480
R1,2 0811-3864 2 RESISTOR 0.6 +-5% 5W PWN TC=0+-90 16 28480
R1,2 0811-3861 2 RESISTOR 1.78 +-1% 5W PWN TC=0+-90 17 28480
R3,7,21,22,105, 0698-3160 6 RESISTOR 31.6K +-1% .125W TF TC=0+-100 ALL 28480
R4,71,73,76,112 0757-0465 5 RESISTOR 100K +-1% .125W TF TC=0+-100 ALL 28480
R5,6,80 0757-0401 3 RESISTOR 100 +-1% .125W TF TC=0+-100 ALL 28480
R8,9,12 0757-0280 3 RESISTOR 1K +-1% .125W TF TC=0+-100 14,15 28480
R8,9 0761-0021 2 RESISTOR 1K +-5% 1W TF TC=0+-100 16,17 28480
R10,108 0699-2715 2 RESISTOR-FUSE 1OHM +-5%; 0.5W @70 ALL 28480
R11 0811-1806 1 RESISTOR 2K +-5% 3W PWI 20PPM 14 28480
R11 0811-2188 1 RESISTOR 5K +-5% 3W PWI 20PPM 15 28480
R11 0764-0007 1 RESISTOR 27K +-5% 2W MO TC=0+-200PPM 16 28480
R11 0699-3105 1 RESISTOR 45K +-5% 2W MO TC=0+-500PPM 17 28480
R13 0757-0461 1 RESISTOR 68.1K +-1% .125W TF TC=0+-100 14,15 28480
R14,48,52 0698-3157 3 RESISTOR 19.6K +-1% .125W TF TC=0+-100 14,15 28480
R15 0757-0442 1 RESISTOR 10K +-1% .125W TF TC=0+-100 14,15 28480
R16 0757-0465 1 RESISTOR 100K +-1% .125W TF TC=0+-100 14,15 28480
R17,18,66,78,110,
123
0757-0280 6 RESISTOR 1K +-1% .125W TF TC=0+-100 ALL 28480
R19,113 0698-0083 2 RESISTOR 1.96K +-1% .125W TF TC=0+-100 ALL 28480
R20,23 0757-0463 2 RESISTOR 82.5K +-1% .125W TF TC=0+-100 ALL 28480
A-14
0160-7673
C33,35,44,45,46,
106
