Table A-10. Replaceable Parts List (Cont'd)
Reference Designator Agilent Part
Number
Q'ty Description Model Mfr. P/N Mfr.
Code
R115 0757-0463 1 RESISTOR 82.5K +-1% .125W TF TC=0+-100 15 28480
R115 0757-0462 1 RESISTOR 75K +-1% .125W TF TC=0+-100 16 28480
R115 0757-0461 1 RESISTOR 68.1K +-1% .125W TF TC=0+-100 17 28480
R116 0698-4489 1 RESISTOR 28K +-1% .125W TF TC=0+-100 14 28480
R116 0698-3161 1 RESISTOR 38.3K +-1% .125W TF TC=0+-100 15,16 28480
R116 0698-4494 1 RESISTOR 35.7K +-1% .125W TF TC=0+-100 17 28480
R118 0698-8678 1 RESISTOR 178 +-1% .125W TF TC=0+-100 ALL 28480
R124 0698-8812 1 RESISTOR 1 +-1% .125W TF TC=0+-100 16,17 28480
R125 0698-8825 1 RESISTOR 681K +-1% .125W TF TC=0+-100 16,17 28480
R126 0757-0401 1 RESISTOR 100 +-1% .125W TF TC=0+-100 ALL 28480
U1 1826-0144 1 IC V RGLTR-FXD-POS 4.8/5.2V TO-220 PKG ALL MC7805CT 04713
U2 1826-0346 1 IC OP AMP GP DUAL 8 PIN DIP-P 14,15 LM358N 27014
U3,16,20 1826-0412 3 IC COMPARATOR PRCN DUAL 8 PIN DIP-P ALL LM393N 27014
U4,5 1826-0138 2 IC COMPARATOR GP QUAD 14 PIN DIP-P ALL LM339 27014
U6,9 1826-0665 2 IC OP AMP LOW-BIAS-H-IMPD QUAD 14 PIN ALL LF347BN 27014
U7,15,17 1826-1297 3 IC V RGLTR-V-REF-FXD 4.8/5.2V TO-92 PKG ALL LM336BZ-5.0 27014
U8 1990-1659 1 OPTO-ISOLATOR LED-TRIAC IF=100MA-MAX ALL MCP3020Z 14936
U10 1826-1702 1 IC OP AMP PRCN 8 PIN DIP-P ALL 28480
U11 1826-1075 1 IC OP AMP GP DUAL 8 PIN DIP-P ALL LF442CN 27014
U12 1826-0468 1 IC V RGLTR-OV-V-SEN 2.3/37.8V 8-DIP-P ALL MC3423P1 04713
U13 1826-0393 1 IC V RGLTR-ADJ-POS 1.2/37V TO-220 PKG ALL LM317T 27014
U14 1826-0221 1 IC V RGLTR-FXD-NEG -11.5/-12.5V TO-220 ALL MC7912CT 04713
U18 1826-0346 1 IC OP AMP GP DUAL 8 PIN DIP-P ALL LM358N 27014
U19 1820-1197 1 IC GATE TTL/LS NAND QUAD 2-INP ALL SN74LS00N 01295
U21,22,23,24 1990-1659 4 OPTO-ISOLATOR LED-TRIAC IF=100MA-MAX 16,17 MCP3020Z 14936
Q1,4 1855-0989 2 TRANSISTOR MOSFET N-CHAN E-MODE TO 247AC 14,15 IRFP044 28480
Q1,4 1855-0536 2 TRANSISTOR MOSFET N-CHAN E-MODE TO-3 SI 16,17 28480
Q2,3,10,11 1854-0477 4 TRANSISTOR NPN 2N2222A SI TO-18 PD=500MW ALL 2N2222A 04713
Q5,6,7,8 1854-0477 4 TRANSISTOR NPN 2N2222A SI TO-18 PD=500MW 14,15 2N2222A 04713
Q6,7 1853-0281 2 TRANSISTOR PNP 2N2907A SI TO-18 PD=400MW 16,17 2N2907A 04713
Q9 1853-0041 1 TRANSISTOR PNP SI TO-39 PD=1W FT=60MHZ ALL MM5007 04713
CR1,19 1901-1273 2 DIODE-PWR RECT 100V 6A 35NS ALL FE6B 14936
CR2 1906-0284 1 DIODE-FW BRIDGE 100V 1A ALL DF01 14936
CR3,4,5,6,7 1901-0033 5 DIODE-GEN PRP 180V 200MA DO-35 14,15 1N645 27014
CR8,9,16,17,31,32 1901-1149 6 DIODE-PWR RECT 400V 1A 50NS DO-41 ALL UF4004 14936
CR10,12,15,18,20 1884-0332 5 THRYSTER-SCR TO-220AB VRRM=200V ALL MCR264-4 04713
CR11,14 1901-1149 2 DIODE-PWR RECT 400V 1A 50NS DO-41 14,15 UF4004 14936
CR13 1906-0400 1 DIODE-BRIDGE 600V 6A ALL GBU8J 14936
A-17
